Paul Wegner GmbH & Co. KG

Doctor Blades Metal

Different industries need different types of blades & knives. Combine your individual metal doctor blade for your needed applications. High qualities and strong controlling measurements guarantee optimal results.

Please take further technical facts from our datasheet at the end of the page.

Material No.:
PW 100

Alloy No.:
2.4375 (Monel)

Description:
Ni Cu 30 AL

Hardness:
HRC:   26 – 32
HV:     270 – 320

Description:
cold rolled and hardened

Tensile strength:
850 – 1050 N/mm²

Surface:
bright

Range of application:
depending on roll cover material

– breast rolls
– press rolls
– steel calanders
