Creping Blades with Ceramic
Due to the permanent technical development in tissue through the last years it has to become more and more necessary to obtain creping blades with a longer life-time and special applications. Get in touch and try the improved creping blades with a ceramic or tungsten carbid coating on the top.
Please take further technical facts from our datasheet at the end of the page.
Alloy No.:
1.0605 (AISI 1075)
Description:
C 75 S
Hardness:
HRC: 48 – 52
HV: 490 – 550
Tensile strength:
1600 – 1800 N/mm²
Length:
after your specification
Standard width in mm:
100 / 110 / 114 / 120 / 125
Standard thickness in mm:
0.9 / 1.0 / 1.25 / 1.5
Surface:
blue polished
Design:
with cut edges, straightened
straightened, grinded 90° on both sides
with one or both sides bevelled from 50° – 85°
Substrate:
Carbon steel
Lay:
Ceramic
Hardness Ceramic:
approx. 1000 HV
Colour Ceramic:
grey
