Description
Model PL-145 Automatic paper lid/cover machine is the ideal equipment for production of paper soup bowl cover, coffee cup lid, paper container lid. The lid made by one disc paper, save cost, paper lid side folded and gentle lock on cup, can block little water out. The machine is easy to operate(a person), stable performance, high efficiency, it introduces the advanced technology completely, can save raw material and the energy consumption is low. It’s a preferred investment business project.
Specifications
Name
Automatic paper lid/cover machine
Model
PL-145
Rated Speed
70~100 pcs/minute; (about 4200~6000 pcs/hour);
Raw Material
Single or double PE coated paper(250-450gsm), coated paper, varnish film paper
Power Source
380V 3-Phase 50Hz
Total Power
10 KW;
Total Weight
2500 KG;
Package Size (L×W×H)
(L*W*H) : 3000*1200*1650 mm
Working Air Source
Air Pressure: 0.4Mpa,Air Out-put : 0.3m3/minute; (Air Compressor Required)
Lid Diameter
55-145mm
Lid Height
8-15mm
