Check Valve

Conval Clampseal® Check Valves are designed for demanding high-pressure applications where light weight and compact size are required.

             Multiple Body Styles

             Versatile

             Performance

             Standard Sizes

             Sizes through 4″

             Pressure Rating

             ASME Class through 4500#

             Standard Forging ASME Materials

             SA105, SA182-F22, SA182-F91, SA182-F92, SA182-F316 Other materials available upon request

             Connections

             SW, BW, FNPT, Grayloc, or Flanged

             Pattern

             Angle, Y, or T pattern

             Configurations

             Piston, Ball, and Stop Check

             DESIGN FEATURES

             Pressure Seal Bonnet

             The simple and effective pressure seal bonnet provides ready access for servicing with no welds to cut or seal rings or gaskets to replace. The body-to-bonnet joint integrity is maintained through countless thermal cycles.

             Only Two Moving Parts

             The valve is comprised of five assemblies, with the piston and spring being the only moving parts. The piston utilizes two guide rings, and the spring is Inconel X for smooth operation in any position.

             Versatility

             CLAMPSEAL® valves are tailored to the exact requirements of our customers. No other premium forged valve offers so many options. Conval provides multiple body styles in various pressure classes and three standard materials. Other materials are available to meet customer needs. The easy interchangeability of parts means that an entire plant installation can be supported with a very low parts inventory.
