SLImline Pump
Machined from solid billet, with a choice of solid Aluminium, Stainless Steel or exotic metals including Hastelloy® and Duplex 22. Flotronic’s fully drainable ‘Slimline’ air operated double diaphragm pumps can be used in a wide range of industries for any liquid transfer, including chemical, cosmetic, paints and coatings, pharmaceutical, adhesive, food and beverage, sanitary and hygienic applications. They have proved particularly effective in the hygienic transfer of viscous products such as cosmetics and foodstuffs including dairy products and mayonnaise. These pumps are manufactured from FDA approved materials and are especially suited to applications where hygiene is paramount and where the avoidance of product hold-up is important.
Flotronic’s ‘Slimline’ pumps may be more compact than competitor AODD pumps, but they’re just as capable - offering all the benefits for which Flotronic pumps are renowned, including Flotronic’s innovative, easy-maintenance, ‘One Nut’ hygienic design which allows pump maintenance in a matter of minutes.
PERFORMANCE TO MATCH ANY REQUIREMENTS:
compact hygienic design ideal when space is limited
FDA approved materials - 316L stainless, Duplex 22, Hastelloy
outside surfaces can be easily cleaned
A range of surface finish is available up to 0.38Ra
a range of ½” to 3” connections, with 7”, 10” or 12” diameter diaphragms, providing in-line adaptability
screwed, hygienic or flanged connections to suit particular applications
Flotronic Pumps’ ‘One-Nut’ technology
readily accessible ball valves
pump air-valve easy to maintain when in-line • a choice of materials to suit any application including Stainless Steel, Aluminium and also exotic metals including Hastelloy®
crevice free design with no internal welding - ideal for hygienic applications and cleaning
fully drainable body
optional hot water/steam jacket
with environmental protection in mind, Diaphragm Rupture Protection and fully pneumatic Alarm Systems are available
optional high temperature diaphragm allows for a 135°C (275°F) maximum operating temperature
self-priming 3.6m/12ft dry and 8m/26ft wet. All of which help you to:
reduce down time and cleaning costs
maintain and even improve on hygienic and sanitary levels on site
