Acelli Paper S.P.A

FINISHING LINES

FINISHING LINES

Lamination

Complete turnkey solution for adhesive, thermal or ultrasonic lamination.

Includes unwind stands, laminating stations and in-line slitting winders.

TECHNICAL DETAILS

• Lamination layers 2 or more
• Max. web width 3600 mm
• Max. master roll ø 1500 mm
• Max. finished reel ø 1500 mm
• Max. operating speed: 400 or 800 m/min**

MAIN FEATURES

• Non-stop or Stop&go unwinders
• Lamination frame
• Hot-melt, ultrasonic or thermobonding system
• Product threading and passage structure
• In-line slitting winder

OPTIONS

• Web accumulation system
• Trim & dust suction system
• DMS
• In-line printing unit
• Master roll and finished reel handling system
