Areas of application
The pressure transmitter is used in cases where it is desired to separate the process medium and the measuring device with a transfer diaphragm. For example, mass-like, crystallizing, hygienic, pulsating, and high-temperature processes.
The different types of pressure transmitters are -
Pressure transmitter, flanged ASME B 16.5 and EN 1092-1
The flanged pressure transmitter is connected to the actual measuring device either directly or via a capillary tube.
Pressure transmitter, threaded, with diaphragm head, LK series
The compact LK series threaded pressure transmitter is especially suitable for small pipelines and applications where the measuring membrane must be flush with the inner surface of the body pipe or tank.
Pressure transmitter, threaded, 2-piece, LD series
When small threaded connections are required for the process connection of the pressure transmitter, the LD series pressure transmitter is a good solution. LD transmitters have a two-part design. The measuring film is attached to the upper part of the transmitter body. The upper and lower parts of the intermediate body are connected to each other by means of clamping rings and screws.
Pressure transmitter, hygienic, LE series
In the food industry processes, pressure transmitters are used in particular for pressure measurements, which are hygienic and easy to wash.
Pressure transmitter, hygienic, with extended diaphragm body, LE-P series
The LE-P series Pressure Transmitters are diaphragm pressure transmitters developed from the traditional SMS series that meet the toughest requirements for hygiene and cleanliness in the food industry.
Pressure transmitter, threaded 1 "LHX6 series (pulp transmitters)
The LHX models are compact transmitters with a diaphragm extension. LHX transmitters can be attached to any process with a weldable connector on the platform, a "saddle" connector on the pipe, or a T-connector that is also suitable for small pipelines.
Pressure transmitter, threaded 1 1/2 "LHX67 series (pulp transmitters)
The LHX models are compact transmitters with a diaphragm extension. LHX transmitters can be attached to the process with weldable connectors on a flat base, a "saddle" connector on the pipe, or a T-connector that is also suitable for small pipelines.
Pressure transmitter, with isolating valve, X3L series
The isolation valve allows the transmitter to be installed / replaced without interrupting the process. The measuring film is located at the level of the process, so that no clogging points are created in the measuring connection.
Pressure Transmitter, Threaded LH Series
Due to its small size, the LH transmitter series is suitable for connection to small body pipes. The intermediate body consists of two parts, the intermediate section and the process connection, which are connected by a union nut.
