GEMÜ Valves Ltd.

Pneumatically operated butterfly valve

Pneumatically operated butterfly valve

Description

The GEMÜ 410 butterfly valve is pneumatically operated. Normally Closed and Normally Open control functions are available. The valve body is available in a plastic design.

Features

• Low weight
• Corrosion resistant plastic body
• Simple installation with union nut
• Space-saving piston actuator made of plastic

Technical specifications

• Media temperature :0 to 60 °C
• Ambient temperature:-10 to 60 °C
• Operating pressure :0 to 6 bar
• Nominal sizes:DN 15 to 50
• Connection types:Union end
• Connection standards:BS | DIN
• Housing materials: PVC-U, grey
• Liner materials:EPDM | FKM
• Disc materials:PVDF
• Conformities:EAC
